Kato HD85V5 Mini Excavator

Back To All Equipment

Kato HD85V5 Mini Excavator


The 85V5 is the largest of all mini excavators from IHI/Compact Excavator Sales, offering more than brute strength to improve productivity in the most demanding work situations.  This all new 18,775lb excavator is a zero-tail-swing machine that comes standard with an additional 900lb counterweight for additional stability.  The 85V5 exhibits power and performance that is paving the way for a new world standard.  This mini excavator offers a comfortable operating environment with a wide cabin that has the largest space in its class.  It has a compact size zero tail swing with a 7’3″ with, especially beneficial when working in tight spaces.


Yanmar 4TNV98C

Engine Output


Maximum Digging Depth


Operating Weight


Financial Available

Contact us for pricing, additional details and documents

Features & Benefits

  • Bucket Capacity - 8.8 cu/ft
  • Bucket Width - 30"
  • Gradeability - 30 degrees
  • Dozer Blade - Lift Above Ground/Drop Below Ground 1'4"/1'5"
We've Got Your Back

We provide support to our clients for maintenance and repair for their equipment.
